Plant & Machinery

Overview

  • Current Production Capacity – Heavy H/Box Beam Structure: – 18000 MT per annum
  • ISO 9001:2008 Certified Company
  • RDSO Approved Fabrication Plant
  • Automated H Beam/Box Welding and drilling lines
  • Total Workshop area: – 36,000 Sq.m Complex
  • Company Spread over a 36000 Sq.m Complex
  • Built Up Area more than 12000 Sq.m
scanner
S.NO. PLANT & MACHINERY SPECIFICATION
1 TOTAL AREA 36000 SQM
2 COVERED AREA 12000 SQM
3 FABRICATION SHED 7500 SQM
4 PAINTING SHED 1000 SQM
5 POWER BACKUP Upto 500 Kva
6 EOT CRANE 20 , 15 MT ( 7.5 MTR LIFT)
7 MAGNETIC LIFTERS UPTO 2 MT.
8 HYDRA 14, 16 MT.
9 CNC CUTTING MACHINE 4000 X 30000 working area With two torches and max capacity of cutting upto 100 mm.
10 PUG CUTTING MACHINE Self propelled manual plate cutting machine.
11 CNC DRILLING MACHINE 4500 x 30000 working bed with two high speed spindles, maximum 40 mm dia hole upto 150 mm thickness.
12 RADIAL DRILL MACHINE 12 - 50 mm dia hole capacity
13 PORTABLE DRILLING MACHINE Upto 85 mm dia hole capacity
14 CANTILEVER BEAM WELDING MACHINE Single cantilever fully automatic with 25 mtr. long bed
15 SUBMERGED ARC WELDING MACHINE 1200 Amps
16 MIG WELDING MACHINE 600Amps
17 WELDING RECTIFIRE / TRANSFORMER 500 Amps
18 H BEAM STRAIGHTENING MACHINE UPTO 80 X 1200 MM
19 STUD WELDING MACHINE 2500Amps (upto 25 dia stud)
20 END FACE MILLING MACHINE 1500 x 1500 mm working area
21 BLASTING EQUIPMENT Sand / Slag
22 AIR COMPRESSOR UPTO 10 BAR
23 METALLISING MACHINE Zinc / Aluminium
24 PAINTING MACHINE Airless Sprayer
